在沼气工程、沼气设备、软体沼气池无论哪种方式，利用前都必须对沼气进行必要的脱硫、脱水、除尘等处理。为了保证沼气产生过程中用户的安全，沼气脱硫脱水系统是沼气生产中必不可少的设备，脱硫脱水设备净化沼气中的有害气体，保证在这一过程中沼气有效安全的产出，济宁力扬环保公司生产的沼气工程设备，具有完善的技术和质量要求，是您放心的选择。
Regardless of the method used in biogas engineering, biogas equipment, or soft biogas digesters, necessary desulfurization, dehydration, dust removal, and other treatments must be carried out on biogas before utilization. In order to ensure the safety of users during the biogas production process, the biogas desulfurization and dehydration system is an essential equipment in biogas production. Desulfurization and dehydration equipment purifies harmful gases in biogas, ensuring the effective and safe output of biogas in this process. The biogas engineering equipment produced by Jining Liyang Environmental Protection Company has complete technical and quality requirements, making it a reliable choice for you.
一、沼气脱硫脱水系统工艺流程：
1、 Process flow of biogas desulfurization and dehydration system:
沼气----脱水----脱硫----阻火----发电或锅炉燃烧
Biogas - Dehydration - Desulfurization - Fire blocking - Power generation or boiler combustion
二、沼气脱硫脱水系统高效脱硫塔的技术参数
2、 Technical parameters of high-efficiency desulfurization tower for biogas desulfurization and dehydration system
1、脱硫效率：≥98％ 脱硫剂：氧化铁及其复合物
1. Desulfurization efficiency: ≥ 98% Desulfurizer: Iron oxide and its composites
三、沼气脱硫脱水系统塔内主要结构及脱硫过程
3、 The main structure and desulfurization process inside the biogas desulfurization and dehydration system tower
根据用户的实际气体气量和气体中硫化qing含量，专门量身设计外形尺寸和内部结构。不同类型的气体，不同气体中硫化qing含量，不同气体压力设计的脱硫设备尺寸不同，内部结构不同。为实时监控再生过程中硫化物及多硫化物与空气中的氧气反应速度，增加温度监控设备，避免因再生过程中通入空气量过大，放热反应剧烈，温度超过脱硫剂的燃点，发生意外火灾。
Tailor designed external dimensions and internal structure based on the actual gas volume and sulfur content of the user. Different types of gases, sulfur content in different gases, and desulfurization equipment designed for different gas pressures have different sizes and internal structures. To monitor the reaction rate of sulfides and polysulfides with oxygen in the air during the regeneration process in real time, temperature monitoring equipment is added to avoid accidental fires caused by excessive air flow during the regeneration process, intense exothermic reactions, and temperatures exceeding the ignition point of the desulfurizer.
四、沼气脱硫脱水系统需要的设备和材料脱硫塔、脱水塔、阻火器、管道、阀门
4、 Equipment and materials required for biogas desulfurization and dehydration system: desulfurization tower, dehydration tower, flame arrester, pipeline, valve
五、沼气脱硫脱水系统更换方法
5、 Replacement method for biogas desulfurization and dehydration system
沼气脱硫剂使用6个月，必须更换。首先关闭沼气净化调压器开关，打开沼气净化脱硫塔进出料口，将脱硫剂在出口掏净，关闭出料口，在进料口填装新脱硫塔，填满后封闭进料口。 更换下的脱硫剂还可再使用，方法是：将更换下来的脱硫剂先除去碎沫，再把颗粒型剂放在阴凉、通风、干燥处2-4天，等到脱硫剂的颜色变成褐色，用塑料袋密封起来，不要受潮、曝晒、压碎，等下次更换使用。换下来的脱硫剂多只能再用两次，但再次使用时间只能在3-4个月。
The biogas desulfurizer must be replaced after being used for 6 months. Firstly, turn off the switch of the biogas purification pressure regulator, open the inlet and outlet of the biogas purification desulfurization tower, clean the desulfurizer at the outlet, close the outlet, fill the inlet with a new desulfurization tower, and then close the inlet. The replaced desulfurizer can still be used. The method is to first remove the foam from the replaced desulfurizer, and then place the granular agent in a cool, ventilated, and dry place for 2-4 days. Wait until the color of the desulfurizer turns brown, seal it with a plastic bag, do not get damp, exposed to sunlight, or crushed, and wait for the next replacement. The replaced desulfurizer can only be reused twice, but the reuse time can only be 3-4 months.
沼气脱硫脱水系统组成由水封器，脱硫器和汽水分离器三部分组成。沼气脱硫脱水系统参数水封器的作用脱硫这一环节，沼气脱硫脱水系统中会用到一个保证安全，不baozha、不着火的中间小设备，这就是水封器，防止回水。一旦瓦斯管内发生baozha或燃烧，由于baozha波和火焰被水封所隔绝，同时使防爆盖自动冲开，baozha能量得到释放，因此可以保护矿井上下、抽放泵站设备及用户的安全。
The biogas desulfurization and dehydration system consists of three parts: a water seal, a desulfurizer, and a steam water separator. The function of the water seal in the parameters of the biogas desulfurization and dehydration system. In the desulfurization process, a small intermediate equipment that ensures safety, is not harmful, and does not catch fire will be used in the biogas desulfurization and dehydration system. This is the water seal to prevent backflow. Once there is a gas explosion or combustion inside the gas pipe, the explosion wave and flame are isolated by the water seal, and the explosion-proof cover automatically bursts open, releasing the energy of the explosion. Therefore, it can protect the safety of the equipment and users of the mining up and down, pumping stations, and pumping stations.
